Name: O-ring NBR rubber Rubber o ring gasket CS/Thickness 1.78mm/0.07in Hydraulic Ring Oil Gas seal gasket AS568-004-029 0.07-1.575in
SKU: 3256802512401450
Availability: InStock

Sale!

O-ring NBR rubber Rubber o ring gasket CS/Thickness 1.78mm/0.07in Hydraulic Ring Oil Gas seal gasket AS568-004-029 0.07-1.575in

O-ring NBR rubber Rubber o ring gasket CS/Thickness 1.78mm/0.07in Hydraulic Ring Oil Gas seal gasket AS568-004-029 0.07-1.575in - Image 2

O-ring NBR rubber Rubber o ring gasket CS/Thickness 1.78mm/0.07in Hydraulic Ring Oil Gas seal gasket AS568-004-029 0.07-1.575in - Image 3

O-ring NBR rubber Rubber o ring gasket CS/Thickness 1.78mm/0.07in Hydraulic Ring Oil Gas seal gasket AS568-004-029 0.07-1.575in - Image 4

O-ring NBR rubber Rubber o ring gasket CS/Thickness 1.78mm/0.07in Hydraulic Ring Oil Gas seal gasket AS568-004-029 0.07-1.575in - Image 5

O-ring NBR rubber Rubber o ring gasket CS/Thickness 1.78mm/0.07in Hydraulic Ring Oil Gas seal gasket AS568-004-029 0.07-1.575in - Image 6

Original price was: $4.96.Current price is: $3.08.

Inner Diameter

ID 1.78mm AS568-004

ID 10.82mm AS568-013

ID 11.1mm

ID 11.2mm

ID 11.3mm

ID 11.8mm

ID 11.91mm

ID 11mm

ID 12.42mm AS568-014

ID 13.3mm

ID 13.5mm

ID 13.8mm

ID 14.8mm

ID 14mm AS568-015

ID 15.6mm AS568-016

ID 15mm

ID 16.67mm

ID 17.17mm AS568-017

ID 17.5mm

ID 17.7mm

ID 18.77mm AS568-018

ID 19.5mm

ID 2.57mm AS568-005

ID 2.85mm

ID 2.9mm AS568-006

ID 20.35mm AS568-019

ID 21.95mm AS568-020

ID 23.52mm AS568-021

ID 24.09mm

ID 25.12mm AS568-022

ID 26.7mm AS568-023

ID 28.3mm AS568-024

ID 29.82mm

ID 29.87mm AS568-025

ID 3.39mm

ID 3.68mm AS568-007

ID 3.94mm

ID 31.47mm AS568-026

ID 32.27mm

ID 32mm

ID 33.05mm AS568-027

ID 34.65mm AS568-028

ID 36.27mm

ID 36.5mm

ID 36mm

ID 37.5mm

ID 37.82mm AS568-029

ID 39.45mm

ID 4.47mm AS568-008

ID 4.76mm

ID 4.87mm

ID 40mm

ID 5.12mm

ID 5.28mm AS568-009

ID 6.07mm AS568-010

ID 6.35mm

ID 6.75mm

ID 7.65mm AS568-011

ID 7.8mm

ID 7.95mm

ID 8.24mm

ID 8.75mm

ID 9.25mm AS568-012

ID 9.75mm

Clear

SKU: 3256802512401450

Description

Standard or Nonstandard: Standard
Shape: Ring Gasket
Model Number: 1.78mm AS568
Material: RUBBER
Brand Name: Hands-online
Certification: RoHS
Origin: Mainland China

[xlmodel]-[custom]-[]

Production Information

NBR Oring Mechanical Seal Rubber Ring Gaskets O-ring Kit O rings nitrile Rubber Gasket Ring seal Washer Seals Mechanical Oil Seal Rubber Ring Gaskets Grommet Ring Seals Ring O Ring caucho guarnizione rubber ring gaskets

ABOUT US

We are professional manufacturer

the products are sold domestically and around the world

We offer:

1. Professional Drop Shipping

2. Ready-made & Custom-made

3. Bulk Price

4. Invoice and Certifications

5. Standard shipping or Express

6. Paypal Payment

O-ring NBR rubber Rubber o ring gasket CS/Thickness 1.78mm/0.07in Hydraulic Ring Oil Gas seal gasket AS568-004-029 0.07-1.575in

Inner Diameter		Outer Diameter
ID(mm)	ID(in)	OD(mm)	OD(in)
1.78	0.070	5.34	0.210
2.57	0.101	6.13	0.241
2.85	0.112	6.41	0.252
2.9	0.114	6.46	0.254
3.39	0.133	6.95	0.274
3.68	0.145	7.24	0.285
3.94	0.155	7.5	0.295
4.47	0.176	8.03	0.316
4.76	0.187	8.32	0.328
4.87	0.192	8.43	0.332
5.12	0.202	8.68	0.342
5.28	0.208	8.84	0.348
6.07	0.239	9.63	0.379
6.35	0.250	9.91	0.390
6.75	0.266	10.31	0.406
7.65	0.301	11.21	0.441
7.8	0.307	11.36	0.447
7.95	0.313	11.51	0.453
8.24	0.324	11.8	0.465
8.75	0.344	12.29	0.484
9.25	0.364	12.81	0.504
9.75	0.384	13.31	0.524
10.82	0.426	14.38	0.566
11	0.433	14.56	0.573
11.1	0.437	14.66	0.577
11.2	0.441	14.76	0.581
11.3	0.445	14.86	0.585
11.8	0.465	15.36	0.605
11.91	0.469	15.47	0.609
12.42	0.489	15.98	0.629
13.3	0.524	16.86	0.664
13.5	0.531	17.06	0.672
13.8	0.543	17.36	0.683
14	0.551	17.56	0.691
14.8	0.583	18.36	0.723
15	0.591	18.56	0.731
15.6	0.614	19.16	0.754
16.67	0.656	20.23	0.796
17.17	0.676	20.73	0.816
17.5	0.689	21.06	0.829
17.7	0.697	21.26	0.837
18.77	0.739	22.33	0.879
19.5	0.768	23.06	0.908
20.35	0.801	23.91	0.941
21.95	0.864	25.51	1.004
23.52	0.926	27.08	1.066
24.09	0.948	27.65	1.089
25.12	0.989	28.68	1.129
26.7	1.051	30.26	1.191
28.3	1.114	31.86	1.254
29.82	1.174	33.38	1.314
29.87	1.176	33.43	1.316
31.47	1.239	35.03	1.379
32	1.260	35.56	1.400
32.27	1.270	35.83	1.411
33.05	1.301	36.61	1.441
34.65	1.364	38.21	1.504
36	1.417	39.56	1.557
36.27	1.428	39.83	1.568
36.5	1.437	40.06	1.577
37.5	1.476	41.06	1.617
37.82	1.489	41.38	1.629
39.45	1.553	43.01	1.693
40	1.575	43.56	1.715
